APC SRT5KXLT Smart-UPS 5.4kVA, 208/240V, LCD, Tower, 2x L6-20R and 2x NEMA L6-30R Outlets.

• Primary Information

  Product Description:	APC Smart-UPS SRT 5000VA - UPS - 4250 Watt - 5000 VA
  Device Type:	UPS - external
  Weight:	120.37 lbs
  Input Voltage:	AC 208 V
  Output Voltage:	AC 208 V ± 3%
  Power Capacity:	4250 Watt / 5000 VA
  Input Connectors:	1 x power NEMA L6-30
  Output connectors:	2 x power NEMA L6-30 ¦ 2 x power NEMA L6-20
  Battery:	Lead acid
  Run Time (Up To):	4 min at full load
  Networking:	Ethernet 10/100, USB
  Color:	Black
  Dimensions (WxDxH):	5.1 in x 28.3 in x 17 in
  Manufacturer Warranty:	3-year warranty
  Designed For:	P/N: SRT5KRMTF, SRT5KTF

• General

  Device Type:	UPS - external
  Color:	Black

• Power Device

  UPS Technology:	On-line
  Input Voltage:	AC 208 V
  Input Voltage Range:	AC 160 - 275 V
  Frequency Provided:	50/60 Hz
  Frequency Required:	45 - 65 Hz
  Input Connectors:	1 x power NEMA L6-30
  Power Output Connectors Details:	2 x power NEMA L6-30 ¦ 2 x power NEMA L6-20
  Output Voltage:	AC 208 V ± 3% - 50/60 Hz
  Power Capacity:	4250 Watt / 5000 VA
  Output Waveform:	Sinewave
  Surge Suppression:	Yes
  Surge Energy Rating:	480 Joules
  Efficiency:	98%

• Battery

  Technology:	Lead acid
  Run Time (Up To):	4 min at full load ¦ 11.8 min at half load
  Recharge Time:	1.5 hours
  Features:	Maintenance free, sealed, leak-proof

• Networking

  Remote Management Interface:

  Ethernet 10/100, USB

• Expansion / Connectivity

  Interfaces:	1 x management (Ethernet) - RJ-45 ¦ 1 x management (USB) - 4 pin USB Type B ¦ 1 x EPO (emergency power off) ¦ 1 x serial - RJ-45
  Expansion Slots:	1 (total) / 1 (free) x SmartSlot

• Miscellaneous

  Cables Included:	Power cable 10 ft
  Features:	Audible alarm, LCD display
  Compliant Standards:	C-Tick, VDE, IEC 60950, EN 50091-2, RoHS, EN 50091-1, REACH, EN 62040-2, IP20, EAC

• Manufacturer Warranty

  Service & Support:

  Limited warranty - 3 years ¦ Limited warranty - batteries - 2 years

• Environmental Parameters

  Min Operating Temperature:	32 °F
  Max Operating Temperature:	104 °F
  Humidity Range Operating:	0 - 95% (non-condensing)

• Dimensions & Weight

  Width:	5.1 in
  Depth:	28.3 in
  Height:	17 in
  Weight:	120.37 lbs

• Dimensions & Weight (Shipping)

  Shipping Width:	24 in
  Shipping Depth:	37.8 in
  Shipping Height:	13 in
  Shipping Weight:	147.71 lbs

• Compatibility Information

  Designed For:

  P/N: SRT5KRMTF, SRT5KTF

• Special Feature

  COO:	PHILIPPINES
  TAA compliance:	No

• UNSPSC Code:

  39121011
